Angled grab rail 45° BF630
500 x 270 mm
- Angled grab rail 45° in robust, germ-reducing and easy-care stainless steel (AISI 304), satin finished.
- Outer diameter of tubes 32 mm for ergonomic hold, clearance from wall 106 mm, bend radii 75 mm.
- Wall mountings with 8-point mounting plate – can be freely rotated, 4 mm thick with 2K-wall sealing-disc.
- Supports weight up to 125 kg.
- Concealed fixings 75 mm in diameter, anti-theft, with silicone sealing ring at tube joint.
- TÜV-certified in accordance with ISO 17966:2016.
- Mounting: With six screws.
- Delivery includes fixing material.
- Length / Weight / Order number
500 mm left-handed / 1,9 kg / 630300
500 mm right-handed / 1,9 kg / 630400 - Intermediate sizes available upon request.
Suggested text for specifications:
Angled grab rail 45° in stainless steel (AISI 304), outer diameter of tubes 32 mm, clearance from wall 106 mm, surface satin finished. Wall mountings with 8-point mounting plate can be freely rotated, 4 mm thick with 2K-wall sealing-disc; supports weight up to 125 kg. Concealed fixings 75 mm in diameter, anti-theft, with silicone sealing ring at tube joint. TÜV-certified in accordance with ISO 17966:2016. Delivery includes fixing material.
Version: left / right
Length 500 x Height 270 mm
Article No. BF630
Angled grab rail 45° in stainless steel (AISI 304), outer diameter of tubes 32 mm, clearance from wall 106 mm, surface satin finished. Wall mountings with 8-point mounting plate can be freely rotated, 4 mm thick with 2K-wall sealing-disc; supports weight up to 125 kg. Concealed fixings 75 mm in diameter, anti-theft, with silicone sealing ring at tube joint. TÜV-certified in accordance with ISO 17966:2016. Delivery includes fixing material.
Version: left / right
Length 500 x Height 270 mm
Article No. BF630
